Addressable Talk Back Console
The Addressable Talkback console is used to have a two-way communication in semi-duplex mode between two points in a multi-storied building or a large area. In this system, the speakers are spread over a large area in the zonal basis. The Console has a selector keypad switches with LCD for visual indication.
Product Specifications
- Effective two-way emergency communication system
- Good quality communication with a clarity output
- Built-in with Feather type keypad switches
- Enclosed with attractive enclosure
- Available in Single and Double loop, Each loop with 150 Nos Speakers with Call Switch and Line Matching Transformer
Technical Specifications
| Operating Voltage | 230 VAC /24 and 5 VDC |
| Power Requirement | 500 VA for a single loop |
| Audio Input | 2 mv |
| Audio Output | Switched Output 100V from Amplifier |
| Visual Indication | 16 X 2 LCD Module |
| Number of Speaker per Loop | 150 Nos |
| Cable Distance | Speaker to Speaker 150 Meters maximum |
| Model Number | RE-65XX |
